Oil Injected - Japan Model

Kobelion VS

Motor Power

22 – 75 kW

Discharge air flow

3.82 – 15.2 m3/min

oil free compressor

Ultimate Efficient Inverter Model

Summit of high-tech for extreme efficiency. Premium energy saver with industrial top notch Air-End, super premium efficiency (1E4 equiv) 1PM motor, built-in overhung design. Much wider range, much better usability.

  • Energy saving with Inverter
  • Super premium efficiency IPM motor (IE4 equiv)
  • Built-in overhung design
  • New Wide Range Control
  • Kobelink compatible
  • Up to 50°C ambient condition
DOWNLOAD BROCURE

BUILT-IN OVER HUNG DESIGN, as identity of KOBELION. Now, you can feel the GENUINE.

  • High efficiency, Motor rotor is directly mounted on the rotor shaft, No coupling, no belt and no gear design realize zero transmission loss.
  • Easy maintenance, With built in overhung design, adjusting and replacing of v-belt is no longer necessary. It is not even required to change or re-grease motor bearings.

Super Premium Efficiency IPM Motor ( IE4 equiv)

New KOBELION VS series equips super premium efficiency IPM (interior permanent magnet) motor, which efficiency is equivalent to 1E4 of IEC standard. IPM has better efficiency from low load to high load compare to induction motor. This IPM is with oil cooled jacket cooling system with insulation class H, which has better resistance to high ambient conditions.



(*)Standard of motor efficiency Is defined by IEC I international Electrotechnical Commission) standard and It defines lEleStandard Efficiency, IE2eHigh Efficiency, 1E3sPrernium Efficiency, and IE4sSuper Premium Efficiency for Induction motor. As IPM Is synchronous motor, IPM Is not defined In this scheme. IPM equipped on VS series has the efficiency beyond 1E4 of induction

New Wide Range Control

In case that required pressure of compressor is 0.5MPa, you may be able to use one size smaller compressor. Wide Range Control of KOBELION VS can deliver much higher flow when it runs at lower pressure point. KOBELION VS senses line pressure and automatically change maximum rpm limit. New KOBELION VS achieves much higher flow and much wider pressure range. Asa leading company of Inverter compressor, we can offer cutting-edge value.



Drastic Increase in discharge air flow



New Generation Smart Controller
NGSC -700 controller as standard

Kobelink – loT cloud service





“NGSC-700 for VS series equips 7.0 inch full color touch operation monitor. Sophisticate LCD interface enables you to figure out following information at a glance.”



  • Operating condition
  • Alarm / Interlock list
  • Compressor settings
  • Daily, Weekly, Monthly record
  • Maintenance schedule
  • Alarm / Trip history
  • Flow diagram
  • etc.

Compressor Group Control

Up to 6 units of compressor can be control by inbuilt sequencing function without external control panel. (Hard wire connections are needed)



(Available only for NGSC.700/430 rnountecl model)



Various User Interface

Other features

  • 3 mode pressure setting
  • Energy saving logic
  • USB data logging
  • Modbus I/O
  • Kobelink-Remote monitoring
  • 7500V lightning surge killer
  • Multi language (JPN/ENG/CHN)
  • Overload protection
  • Instant power failure ride-through : [ SG ] —0.3 sec [VS] —0.5 sec
  • Automatic restart : 5-20 sec
  • Reverse phase protection
  • etc.

Data logging with USB

  • Running data (CSV file) can be output from monitor to USB memory stick.
